Komatsu
Terex
33-11C
Off-Highway Truck
19 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Fuel Capacity | 501.9 gal |
|---|---|
| Tire Size | 30.00-51-46PR |
| Engine Oil Capacity | 38.4 gal |
| Cooling System Fluid Capacity | 66.1 gal |
Engine
| Engine Model | KTA-2300C |
|---|---|
| Displacement | 2,300 in³ |
| Gross Power | 1,200.0 hp |
| Net Power | 1,160.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | — |
Weights
| Empty Weight | 189,157 lb |
|---|---|
| Loaded Weight | 453,833 lb |
| Weight Distribution Front - loaded | 32.0 % |
| Weight Distribution Rear - loaded | 68.0 % |
| Weight Distribution Front - empty | 43.1 % |
| Weight Distribution Rear - empty | 56.9 % |
Dimensions
| Ground Clearance | 29 in |
|---|---|
| Wheelbase | 214 in |
| Overall Length | 428 in |
| Overall Width | 258 in |
| Overall Height | 204 in |
| Dump Height | 411 in |
| Dump Ground Clearance | 66 in |
Transmission
| Max Speed | 35.8 mph |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 239,973.9 gal |
|---|
Dump
| Dump Angle | 48 ° |
|---|---|
| Load Capacity - heaped | 91.60 yd³ |
| Load Capacity - Struck | 60.30 yd³ |
