Komatsu
Case
602BPD
Smooth Drum Roller
25 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 23,700 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 68.7 gal |
Engine
| Engine Model | S6D102E |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 133.1 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 117 in |
| Wheelbase | 10 in |
| Overall Length | 18 in |
| Overall Width | 84 in |
| Drum Diameter - Front | 60 in |
Drum
| Drum Width | 84 in |
|---|---|
| Drum Diameter | 60 in |
| Vibration Frequency 1 | 17 vpm |
| Vibration Frequency 2 | 30 vpm |
