Komatsu
Ingersoll Rand
DD14S
Smooth Drum Roller
17 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 5,203 lb |
|---|---|
| Max Speed | 6.3 mph |
| Fuel Capacity | 9.6 gal |
Engine
| Engine Model | 3D78AE |
|---|---|
| Displacement | 73 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 23.1 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 69 in |
| Wheelbase | 6 in |
| Overall Length | 9 in |
| Overall Width | 52 in |
| Drum Diameter - Front | 33 in |
Drum
| Drum Width | 47 in |
|---|---|
| Drum Diameter | 34 in |
| Vibration Frequency 1 | 55 vpm |
| Centrifugal Force - MEd | 5,510 lb |
