KomatsuKomatsu
PW95-1
Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 32,783 lb |
|---|---|
| Fuel Capacity | 52.9 gal |
| Hydraulic System Fluid Capacity | 18.3 gal |
| Engine Oil Capacity | 3.1 gal |
| Cooling System Fluid Capacity | 4.7 gal |
| Swing Drive Fluid Capacity | 0.7 gal |
Engine
| Engine Model | SAA4D95LE-6 |
|---|---|
| Displacement | 199 in³ |
| Power Measured @ | 2,050 rpm |
| Gross Power | 97.3 hp |
| Net Power | 93.5 hp |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 111 in |
| Length of Track on Ground | 143 in |
| Tail Swing Radius | 59 in |
| Removal Counterweight Clearance | 36 in |
Undercarriage
| Number of Track Rollers per Side | 1 |
|---|---|
| Max Travel Speed | 3.2 mph |
| Number of Shoes per Side | 43 |
| Number of Carrier Rollers per Side | 7 |
| Drawbar Pull | 27,558 lb |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
