Komatsu
PC210-6
- Operating Weight
- 45,195 lb
- Max Digging Depth
- 219 in
- Max Digging Depth
- 240 in
- Net Power
- 133.0 hp
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Operating Weight | 45,195 lb |
|---|---|
| Fuel Capacity | 89.9 gal |
| Hydraulic Pump Flow Capacity | 108.9 gal/min |
| Hydraulic System Fluid Capacity | 43.9 gal |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.5 gal |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | S6D102E |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 140.0 hp |
| Net Power | 133.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 115 in |
| Length of Track on Ground | 128 in |
| Tail Swing Radius | 109 in |
| Width to Outside of Tracks | 110 in |
| Removal Counterweight Clearance | 43 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 86 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 449 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 39,022 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 219 in |
|---|---|
| Max Reach Along Ground | 344 in |
| Max Loading Height | 239 in |
| Max Vertical Wall Digging Depth | 196 in |
| Max Cutting Height | 350 in |
| Shipping Length of Unit | 371 in |
| Shipping Height of Unit | 115 in |
Bucket
| Reference Bucket Capacity | 1.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.60 yd³ |
| Minimum Bucket Capacity | 0.60 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Vertical Wall Digging Depth | 210 in |
| Max Cutting Height | 356 in |
| Max Loading Height | 247 in |
| Max Reach Along Ground | 364 in |
| Shipping Length of Unit | 374 in |
| Shipping Height of Unit | 124 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 261 in |
|---|---|
| Max Cutting Height | 367 in |
| Max Loading Height | 256 in |
| Max Vertical Wall Digging Depth | 236 in |
| Max Reach Along Ground | 383 in |
| Shipping Length of Unit | 372 in |
| Shipping Height of Unit | 118 in |
