EX135USR
Excavator
23 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 48,502 lb |
|---|---|
| Fuel Capacity | 68.7 gal |
| Hydraulic Pump Flow Capacity | 155.9 gal/min |
| Hydraulic System Fluid Capacity | 76.7 gal |
| Hydraulic System Relief Valve Pressure | 3,560 psi |
Engine
| Engine Model | S6D105 |
|---|---|
| Displacement | 396 in³ |
| Net Power | 136.0 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Length of Track on Ground | 132 in |
| Tail Swing Radius | 119 in |
| Width to Outside of Tracks | 119 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 95 in |
| Max Travel Speed | 1.9 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 261 in |
|---|---|
| Max Loading Height | 258 in |
| Max Vertical Wall Digging Depth | 230 in |
| Max Cutting Height | 372 in |
| Shipping Length of Unit | 393 in |
| Shipping Height of Unit | 120 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
