313F L
Excavator
23 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 55,129 lb |
|---|---|
| Fuel Capacity | 107.7 gal |
| Hydraulic System Fluid Capacity | 34.9 gal |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 9.5 gal |
| Swing Drive Fluid Capacity | 2.0 gal |
Engine
| Engine Model | SAA6D107E-2 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 189.0 hp |
| Net Power | 177.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 152 in |
| Tail Swing Radius | 117 in |
| Width to Outside of Tracks | 133 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Number of Track Rollers per Side | 10 |
|---|---|
| Max Travel Speed | 3.4 mph |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 45,349 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 272 in |
|---|---|
| Max Reach Along Ground | 385 in |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
