Komatsu

PC290LC-6

Excavator

Operating Weight
62,832 lb
Max Digging Depth
214 in
Max Digging Depth
234 in
Net Power
174.0 hp
All excavators
Komatsu PC290LC-6 Excavator
1 / 5
Image 1 of 5
Image: smsequipment.com

Specifications

54 data points

Operating Specifications

Operating Specifications specifications
Operating Weight62,832 lb
Fuel Capacity89.9 gal
Hydraulic Pump Flow Capacity141.6 gal/min
Hydraulic System Fluid Capacity43.9 gal
Hydraulic System Relief Valve Pressure5,049 psi
Engine Oil Capacity7.0 gal
Cooling System Fluid Capacity6.5 gal
Operating Voltage24 V
Swing Drive Fluid Capacity1.5 gal
Alternator Supplied Amperage55 A

Engine

Engine specifications
Engine ModelSA6D102EA-1
Displacement359 in³
Power Measured @2,200 rpm
Gross Power185.0 hp
Net Power174.0 hp
AspirationTurbrocharged

Undercarriage

Undercarriage specifications
Ground Pressure8 psi
Number of Track Rollers per Side7
Max Travel Speed3.3 mph
Shoe Size24 in
Number of Shoes per Side45
Number of Carrier Rollers per Side2
Drawbar Pull50,706 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth214 in
Max Reach Along Ground354 in
Max Loading Height254 in
Max Vertical Wall Digging Depth189 in
Max Cutting Height367 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed11 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth234 in
Max Vertical Wall Digging Depth211 in
Max Cutting Height371 in
Max Loading Height261 in
Max Reach Along Ground371 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth254 in
Max Cutting Height384 in
Max Loading Height271 in
Max Vertical Wall Digging Depth228 in
Max Reach Along Ground391 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth272 in
Max Cutting Height389 in
Max Reach Along Ground407 in
Max Loading Height280 in
Max Vertical Wall Dig Depth248 in

Boom/Stick Excavator Option 5

Boom/Stick Excavator Option 5 specifications
Max Digging Depth204 in
Max Reach Along Ground360 in
Max Cutting Height406 in
Max Loading Height284 in
Max Vertical Wall Dig Depth98 in

Boom/Stick Excavator Option 6

Boom/Stick Excavator Option 6 specifications
Max Digging Depth260 in
Max Reach Along Ground414 in
Max Cutting Height439 in
Max Loading Height311 in
Max Vertical Wall Dig Depth149 in
