Case
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 37,700 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Hydraulic Pump Flow Capacity | 37.5 gal/min |
| Hydraulic System Fluid Capacity | 43.6 gal |
| Engine Oil Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 4.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.4 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 4JJ1X Tier III certified |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 120.0 hp |
| Aspiration | turbocharged and aftercooled |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 288 lb-ft |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 115 in |
| Length of Track on Ground | 126 in |
| Tail Swing Radius | 96 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 41 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 44 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 36,194 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 257 in |
|---|---|
| Max Reach Along Ground | 364 in |
| Max Loading Height | 264 in |
| Max Vertical Wall Digging Depth | 206 in |
| Max Cutting Height | 366 in |
| Shipping Length of Unit | 336 in |
| Shipping Height of Unit | 124 in |
Bucket
| Maximum Bucket Capacity | 0.99 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Vertical Wall Digging Depth | 200 in |
| Max Cutting Height | 365 in |
| Max Loading Height | 230 in |
| Max Reach Along Ground | 349 in |
| Shipping Length of Unit | 332 in |
| Shipping Height of Unit | 118 in |
