Komatsu
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 90,610 lb |
|---|---|
| Fuel Capacity | 159.9 gal |
| Hydraulic Pump Flow Capacity | 141.6 gal/min |
| Hydraulic System Fluid Capacity | 49.7 gal |
| Hydraulic System Relief Valve Pressure | 5,405 psi |
| Engine Oil Capacity | 9.3 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 3.6 gal |
| Alternator Supplied Amperage | 60 A |
Engine
| Engine Model | SAA6D114E-2 |
|---|---|
| Displacement | 505 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 241.4 hp |
| Aspiration | Turbocharged with aftercooler |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 151 in |
| Width to Outside of Tracks | 130 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 59,304 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 689 in |
|---|---|
| Max Reach Along Ground | 805 in |
| Max Loading Height | 531 in |
| Max Vertical Wall Digging Depth | 563 in |
| Max Cutting Height | 641 in |
| Shipping Length of Unit | 678 in |
| Shipping Height of Unit | 134 in |
Bucket
| Reference Bucket Capacity | 0.60 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
