Komatsu
Kobelco
235SR LC
Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 95,460 lb |
|---|---|
| Fuel Capacity | 172.0 gal |
| Hydraulic System Fluid Capacity | 65.5 gal |
| Engine Oil Capacity | 10.0 gal |
| Cooling System Fluid Capacity | 9.0 gal |
| Swing Drive Fluid Capacity | 4.3 gal |
Engine
| Engine Model | SAA6D125E-3 |
|---|---|
| Power Measured @ | 1,850 rpm |
| Net Power | 330.0 hp |
Dimensions
| Ground Clearance | 53 in |
|---|---|
| Height - Top of Cab | 130 in |
| Length of Track on Ground | 211 in |
| Tail Swing Radius | 144 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Max Travel Speed | 3.4 mph |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 73,962 lb |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
