Liebherr
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 57,320 lb |
|---|---|
| Fuel Capacity | 95.2 gal |
| Hydraulic Pump Flow Capacity | 105.7 gal/min |
| Hydraulic System Fluid Capacity | 60.8 gal |
| Hydraulic System Relief Valve Pressure | 5,221 psi |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | D 924 T-E |
|---|---|
| Power Measured @ | 2,000 rpm |
| Net Power | 132.8 hp |
| Aspiration | In-line engine water-cooled |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 128 in |
| Length of Track on Ground | 133 in |
| Tail Swing Radius | 108 in |
| Removal Counterweight Clearance | 46 in |
Undercarriage
| Max Travel Speed | 3.2 mph |
|---|---|
| Shoe Size | 20 in |
| Drawbar Pull | 60,923 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 154 in |
|---|---|
| Max Reach Along Ground | 330 in |
| Max Loading Height | 252 in |
| Max Vertical Wall Digging Depth | 108 in |
| Max Cutting Height | 342 in |
| Shipping Length of Unit | 438 in |
| Shipping Height of Unit | 146 in |
