R950 SME Litronic
Excavator
41 specifications
1 / 5
Image 1 of 5
Specifications
76 data points
Operating Specifications
| Operating Weight | 168,092 lb |
|---|---|
| Fuel Capacity | 232.5 gal |
| Hydraulic Pump Flow Capacity | 266.3 gal/min |
| Hydraulic System Fluid Capacity | 116.3 gal |
| Hydraulic System Relief Valve Pressure | 4,552 psi |
| Engine Oil Capacity | 10.1 gal |
| Cooling System Fluid Capacity | 22.5 gal |
| Swing Drive Fluid Capacity | 8.0 gal |
| Swing Speed | 6 rpm |
Engine
| Engine Model | SAA6D140E-2 |
|---|---|
| Displacement | 930 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 444.0 hp |
| Net Power | 443.9 hp |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 33 in |
|---|---|
| Length of Track on Ground | 178 in |
| Tail Swing Radius | 170 in |
| Width to Outside of Tracks | 162 in |
| Removal Counterweight Clearance | 62 in |
| Upper Structure Ground Clearance | 62 in |
| Length of Tracks | 229 in |
Undercarriage
| Ground Pressure | 17 psi |
|---|---|
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 47 |
| Number of Carrier Rollers per Side | 3 |
| Number of Upper Rollers | 47 |
| Number of Lower Rollers | 8 |
| Backhoe Shoe Width 1 | 24 in |
| Backhoe Operating Weight - Shoe 1 | 168,092 lb |
| Backhoe Ground Pressure - Shoe 1 | 18 psi |
| Number of Track Shoes per Side | 3 |
| Tail Swing Radius | 169 in |
| Backhoe Shoe Width 2 | 28 in |
| Backhoe Ground Pressure - Shoe 2 | 16 psi |
| Backhoe Operating Weight - Shoe 2 | 169,635 lb |
| Backhoe Shoe Width 3 | 32 in |
| Backhoe Ground Pressure - Shoe 3 | 14 psi |
| Backhoe Operating Weight - Shoe 3 | 171,178 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 277 in |
|---|---|
| Max Reach Along Ground | 468 in |
| Max Loading Height | 299 in |
| Max Vertical Wall Digging Depth | 194 in |
| Max Cutting Height | 454 in |
| Shipping Length of Unit | 507 in |
| Shipping Height of Unit | 186 in |
Bucket
| Reference Bucket Capacity | 5.30 yd³ |
|---|---|
| Maximum Bucket Capacity | 5.90 yd³ |
| Minimum Bucket Capacity | 5.30 yd³ |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
Loading Shovel
| Max Dig Depth | 135 in |
|---|---|
| Max Cutting Height | 418 in |
| Max Dump Height | 301 in |
| Max Dig Reach | 393 in |
| Height to Top of Boom - shovel | 200 in |
| Overall Length - shovel | 385 in |
| Loading Shovel | 3.8 m (cube) bottom dump bucket |
| Arm Crowd Force | 99,207 lb-ft |
Backhoe Boom / Stick 1
| Max Dig Depth | 277 in |
|---|---|
| Max Cutting Height | 454 in |
| Max Dump Height | 299 in |
| Max Reach on Ground | 468 in |
| Max Vertical Wall Dig Depth | 194 in |
| Arm Crowd Force | 74,515 lb-ft |
| Height to Top of Boom | 186 in |
| Overall Length | 507 in |
Backhoe Boom / Stick 2
| Max Dig Depth | 332 in |
|---|---|
| Max Cutting Height | 472 in |
| Max Dump Height | 324 in |
| Max Reach on Ground | 528 in |
| Max Vertical Wall Dig Depth | 231 in |
| Arm Crowd Force | 64,153 lb-ft |
| Height to Top of Boom | 189 in |
| Overall Length | 545 in |
