Link Belt
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
59 data points
Operating Specifications
| Operating Weight | 101,200 lb |
|---|---|
| Fuel Capacity | 161.2 gal |
| Hydraulic Pump Flow Capacity | 190.2 gal/min |
| Hydraulic System Fluid Capacity | 118.9 gal |
| Hydraulic System Relief Valve Pressure | 4,970 psi |
| Engine Oil Capacity | 8.8 gal |
| Cooling System Fluid Capacity | 12.1 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 2.8 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AA-6SD1XQB |
|---|---|
| Displacement | 600 in³ |
| Power Measured @ | 1,950 rpm |
| Aspiration | Turbocharged with Intercooler |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 940 lb-ft |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 132 in |
| Length of Track on Ground | 174 in |
| Tail Swing Radius | 143 in |
| Width to Outside of Tracks | 144 in |
| Removal Counterweight Clearance | 53 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Track Gauge | 109 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.3 mph |
| Shoe Size | 36 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 271 in |
|---|---|
| Max Reach Along Ground | 433 in |
| Max Loading Height | 293 in |
| Max Vertical Wall Digging Depth | 224 in |
| Max Cutting Height | 426 in |
| Shipping Length of Unit | 473 in |
| Shipping Height of Unit | 144 in |
Bucket
| Reference Bucket Capacity | 2.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 4.09 yd³ |
| Minimum Bucket Capacity | 1.60 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 305 in |
|---|---|
| Max Vertical Wall Digging Depth | 259 in |
| Max Cutting Height | 439 in |
| Max Loading Height | 305 in |
| Max Reach Along Ground | 465 in |
| Shipping Length of Unit | 470 in |
| Shipping Height of Unit | 143 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 329 in |
|---|---|
| Max Cutting Height | 448 in |
| Max Loading Height | 313 in |
| Max Vertical Wall Digging Depth | 282 in |
| Max Reach Along Ground | 486 in |
| Shipping Length of Unit | 470 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 362 in |
|---|---|
| Max Cutting Height | 468 in |
| Max Reach Along Ground | 521 in |
| Max Loading Height | 332 in |
| Max Vertical Wall Dig Depth | 324 in |
| Shipping Length of Unit | 473 in |
