Liebherr
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 100,860 lb |
|---|
Engine
| Engine Model | D936 A7 |
|---|---|
| Displacement | 640 in³ |
| Power Measured @ | 1,800 rpm |
| Torque Measured @ | 1,000 rpm |
| Max Torque | 1,451 lb-ft |
| Stroke | 6 in |
| Bore | 5 in |
| Emission Tier Level | Tier 4 Final |
| Air cleaner | Dry-type |
| Cooling system | water-cooled |
| Horsepower, Net-ISO 9249 | 299.0 hp |
| Horsepower, Net-SAE J1349 | 295.0 hp |
Hydraulic System
| system pressure | 5,511 psi |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 115 in |
| Wheelbase | 174 in |
| Undercarriage Width | 144 in |
Undercarriage
| Number of Track Rollers per Side | 10 |
|---|---|
| Max Travel Speed | 3.0 mph |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 78,234 lb |
Fluid Capacities
| Fuel Tank | 188.0 gal |
|---|---|
| Hydraulic system | 156.0 gal |
| Urea tank | 25.0 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 241 in |
|---|---|
| Maximum Reach at Ground Level | 397 in |
| Max. teeth height | 397 in |
| Breakout force - ISO | 59,300 lb |
| Digging force - ISO | 54,680 lb |
Bucket
| Maximum Bucket Capacity | 4.00 yd³ |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 271 in |
|---|---|
| Max.Dumping Height | 282 in |
| Max. teeth height | 426 in |
| Maximum Reach at Ground Level | 35 in |
| Breakout force-ISO | 59,300 lb |
| Digging force - ISO | 47,840 lb |
Electrical System
| Batteries | 2 x 180 Ah / 12 V volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
| Engine idling | Sensor controlled |
