Komatsu
Liebherr
R950 SME Litronic
Excavator
41 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 168,092 lb |
|---|---|
| Fuel Capacity | 232.5 gal |
| Hydraulic Pump Flow Capacity | 129.0 gal/min |
| Hydraulic System Fluid Capacity | 116.3 gal |
| Engine Oil Capacity | 14.6 gal |
| Cooling System Fluid Capacity | 22.5 gal |
| Swing Drive Fluid Capacity | 6.5 gal |
Engine
| Engine Model | SAA6D140E-3 |
|---|---|
| Displacement | 930 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 454.0 hp |
| Aspiration | Turbocharged with aftercooler |
Dimensions
| Ground Clearance | 33 in |
|---|---|
| Height - Top of Cab | 137 in |
| Length of Track on Ground | 178 in |
| Tail Swing Radius | 170 in |
| Width to Outside of Tracks | 162 in |
| Removal Counterweight Clearance | 62 in |
Undercarriage
| Ground Pressure | 18 psi |
|---|---|
| Track Gauge | 138 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 47 |
| Number of Carrier Rollers per Side | 3 |
| Drawbar Pull | 125,663 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 281 in |
|---|---|
| Max Reach Along Ground | 470 in |
| Max Loading Height | 296 in |
| Max Vertical Wall Digging Depth | 161 in |
| Max Cutting Height | 446 in |
| Shipping Length of Unit | 514 in |
| Shipping Height of Unit | 182 in |
Bucket
| Reference Bucket Capacity | 5.30 yd³ |
|---|---|
| Maximum Bucket Capacity | 7.90 yd³ |
| Minimum Bucket Capacity | 4.80 yd³ |
Swing Mechanism
| Swing Speed | 7 rpm |
|---|
