Komatsu
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
61 data points
Operating Specifications
| Operating Weight | 33,312 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 62.4 gal/min |
| Hydraulic System Fluid Capacity | 26.5 gal |
| Hydraulic System Relief Valve Pressure | 4,623 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 4.2 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 45 A |
| Hydraulic Pump Type | variable displacement piston |
| Oscillating Axle Angle | 14 ° |
| Front Diff Fluid Capacity | 4.0 gal |
| Rear Diff Fluid Capacity | 5.3 gal |
Engine
| Engine Model | SA4D102E-1 |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,250 rpm |
| Gross Power | 110.0 hp |
| Net Power | 105.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 134 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Tail Swing Radius | 84 in |
| Upper Structure Clearance | 48 in |
Transmission
| Max Travel Speed | 18.7 mph |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.50 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 187 in |
|---|---|
| Max Cutting Height | 342 in |
| Max Reach Along Ground | 304 in |
| Max Loading Height | 248 in |
| Shipping Length of Unit | 300 in |
| Shipping Height of Unit | 121 in |
| Max Vertical Wall Dig Depth | 165 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 203 in |
|---|---|
| Max Cutting Height | 350 in |
| Max Reach Along Ground | 318 in |
| Max Loading Height | 258 in |
| Shipping Height of Unit | 137 in |
| Shipping Length of Unit | 294 in |
| Max Vertical Wall Dig Depth | 180 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 198 in |
|---|---|
| Max Cutting Height | 352 in |
| Max Reach Along Ground | 313 in |
| Max Loading Height | 258 in |
| Shipping Height of Unit | 156 in |
| Shipping Length of Unit | 227 in |
| Max Vertical Wall Dig Depth | 157 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 214 in |
|---|---|
| Max Cutting Height | 362 in |
| Max Reach Along Ground | 329 in |
| Max Loading Height | 272 in |
| Shipping Height of Unit | 156 in |
| Shipping Length of Unit | 226 in |
| Max Vertical Wall Dig Depth | 173 in |
