Komatsu
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 41,844 lb |
|---|---|
| Fuel Capacity | 74.0 gal |
| Hydraulic Pump Flow Capacity | 116.0 gal/min |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
Engine
| Engine Model | S6D105 |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 152.9 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 110 in |
| Overall Width | 9 in |
| Tail Swing Radius | 107 in |
| Upper Structure Clearance | 52 in |
Transmission
| Max Travel Speed | 21.7 mph |
|---|---|
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.60 yd³ |
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 229 in |
|---|---|
| Max Cutting Height | 362 in |
| Max Reach Along Ground | 361 in |
| Max Loading Height | 254 in |
| Shipping Length of Unit | 374 in |
| Shipping Height of Unit | 148 in |
| Max Vertical Wall Dig Depth | 211 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 248 in |
|---|---|
| Max Cutting Height | 356 in |
| Max Reach Along Ground | 378 in |
| Max Loading Height | 258 in |
| Shipping Height of Unit | 148 in |
| Shipping Length of Unit | 373 in |
| Max Vertical Wall Dig Depth | 226 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 204 in |
|---|---|
| Max Cutting Height | 352 in |
| Max Reach Along Ground | 339 in |
| Max Loading Height | 245 in |
| Max Vertical Wall Dig Depth | 186 in |
