Komatsu
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 8,770 lb |
|---|---|
| Fuel Capacity | 15.9 gal |
| Tire Size | 10.20-10PR (L-2) |
| Static Tipping Weight | 5,291 lb |
| Turning Radius | 168 in |
| Cooling System Fluid Capacity | 3.2 gal |
Engine
| Engine Model | 4D94 |
|---|---|
| Displacement | 179 in³ |
| Gross Power | 49.0 hp |
Dimensions
| Height - Top of Cab | 113 in |
|---|---|
| Wheelbase | 85 in |
| Width Over Tires | 71 in |
| Reach at Max Lift and Dump | 36 in |
| Length with Bucket on Ground | 178 in |
| Hinge Pin - Max Height | 113 in |
Transmission
| Max Speed - Forward | 15.6 mph |
|---|---|
| Max Speed - Reverse | 6.3 mph |
| Transmission Type | TORQFLOW full power shift countershaft |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 1 |
Bucket
| Bucket Capacity - heaped | 0.80 yd³ |
|---|---|
| Dump Clearance at Max Raise | 89 in |
| Breakout Force | 6,940 lb |
| Bucket Width | 76 in |
