Komatsu
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 16,954 lb |
|---|---|
| Fuel Capacity | 35.2 gal |
| Tire Size | 16.9-24 |
| Static Tipping Weight | 13,889 lb |
| Rear Axle Oscillation | 24 ° |
Engine
| Engine Model | 6D95L |
|---|---|
| Displacement | 299 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 63.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 30.4 gal/min |
|---|
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 121 in |
| Wheelbase | 103 in |
| Width Over Tires | 89 in |
| Reach at Max Lift and Dump | 40 in |
| Length with Bucket on Ground | 239 in |
| Hinge Pin - Max Height | 137 in |
Transmission
| Max Speed - Forward | 21.5 mph |
|---|---|
| Max Speed - Reverse | 21.8 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.90 yd³ |
|---|---|
| Bucket Capacity - struck | 1.60 yd³ |
| Dump Clearance at Max Raise | 107 in |
| Breakout Force | 13,490 lb |
| Bucket Width | 95 in |
