Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
14 data points
Operating Specifications
| Rated Bucket Capacity | 2.20 – 3.10 yd³ |
|---|
Engine
| Net Power | 126.0 hp |
|---|
Weights
| Operating Weight | 25,827 – 26,489 lb |
|---|
Bucket
| Dump Clearance at Max Raise | 118 in |
|---|
General Specifications
| Operating Weight | 25,827 - 26,489 (11,715 - 12,015) Starting 2019 Model Year |
|---|---|
| Operating Weight lbs (kg) | 25,827 - 26,489 (11,715 - 12,015) Starting 2025 Model Year |
| Bucket Capacity | 2.6 - 3.1 (2.0 - 2.4) Starting 2019 Model Year |
| Bucket Capacity cu. yd. (cu m) | 2.6 - 3.1 (2.0 - 2.4) Starting 2025 Model Year |
| Engine type | SAA4D107E-3 Starting 2019 Model Year |
| Engine Power | 126 (94) Starting 2019 Model Year |
| Max Dump Height | 9.7 (2.9) with pin on GP bucket Starting 2024 Model Year |
| Max Dump Height ft.( m) | 9.8 (2.9) with pin on GP bucket Starting 2026 Model Year |
| OperatingWeight lbs. (kg) | 25,827 - 26,489 (11,715 - 12,015) Starting 2026 Model Year |
| Engine Power Net hp (kW) | 126 (94) Starting 2025 Model Year |
