Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 25,166 lb |
|---|---|
| Fuel Capacity | 48.7 gal |
| Tire Size | 17.5-25-12PR |
| Static Tipping Weight | 19,026 lb |
Engine
| Engine Model | S6D102E-1 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 130.1 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 115 in |
| Width Over Tires | 91 in |
| Reach at Max Lift and Dump | 42 in |
| Length with Bucket on Ground | 285 in |
| Hinge Pin - Max Height | 150 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 24.3 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 2.50 yd³ |
|---|---|
| Dump Clearance at Max Raise | 110 in |
| Breakout Force | 26,983 lb |
| Bucket Width | 107 in |
