Komatsu
Caterpillar
992G
Wheel Loader
85 specifications
Komatsu
WA900-3 Tier 2
- Operating Weight
- 236,340 lb
- Bucket Capacity - heaped
- 17.09 yd³
- Gross Power
- 900.0 hp
- Net Power
- 856.0 hp
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Operating Weight | 236,340 lb |
|---|---|
| Fuel Capacity | 410.8 gal |
| Tire Size | 45/65-45 |
| Hydraulic System Fluid Capacity | 191.6 gal |
| Static Tipping Weight | 144,780 lb |
| Operating Voltage | 24 V |
| Turning Radius | 433 in |
| Engine Oil Fluid Capacity | 34.4 gal |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 90 A |
| Front Axle/Diff Fluid Capacity | 95.2 gal |
| Rear Axle/Diff Fluid Capacity | 95.2 gal |
| Cooling System Fluid Capacity | 89.1 gal |
| Transmission Fluid Capacity | 37.0 gal |
| Rated Bucket Capacity | 15.00 – 17.00 yd³ |
Engine
| Engine Model | SAA12V140E-3 |
|---|---|
| Displacement | 1,860 in³ |
| Power Measured @ | 2,050 rpm |
| Gross Power | 900.0 hp |
| Net Power | 856.0 hp |
| Number of Cylinders | 12 |
| Aspiration | Turbocharged and Aftercooled |
Weights
| Operating Weight | 236,340 – 236,670 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 83.3 gal/min |
|---|---|
| Raise Time | 11.2 s |
| Lower Time | 4.8 s |
| Dump Time | 2.0 s |
| Relief Valve Setting | 4,977 psi |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 209 in |
| Wheelbase | 215 in |
| Width Over Tires | 181 in |
| Reach at Max Lift and Dump | 97 in |
| Length with Bucket on Ground | 571 in |
| Hinge Pin - Max Height | 275 in |
Transmission
| Max Speed - Forward | 10.9 mph |
|---|---|
| Max Speed - Reverse | 11.0 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 17.09 yd³ |
|---|---|
| Bucket Capacity - struck | 14.40 yd³ |
| Dump Clearance at Max Raise | 183 in |
| Breakout Force | 149,690 lb |
| Bucket Width | 190 in |
