Komatsu

WS16S-2

Scraper

Gross Power
364.0 hp
Max Speed - Forward
32.4 mph
All scrapers
Komatsu WS16S-2 Scraper
1 / 5
Image 1 of 5
Image: machinecatalogic.com

Specifications

21 data points

Weights

Weights specifications
Total Operating - empty67,902 lb
Total Operating - Loaded117,727 lb

Dimensions

Dimensions specifications
Height - Top of Cab139 in
Wheelbase95 in
Overall Length504 in
Overall Width138 in
Overall Height176 in
Tractor Ground Clearance26 in

Transmission

Transmission specifications
Max Speed - Forward32.4 mph
Number of Forward Gears8
Number of Reverse Gears1
Transmission TypeTORQFLOW planetary gear type

Bowl

Bowl specifications
Heaped Capacity21.01 yd³
Width of Cut126 in
Max Depth of Cut15 in
Rated Payload49,384 lb
Struck Capacity14.40 yd³

Tractor Engine

Tractor Engine specifications
Gross Power364.0 hp
Displacement855 in³
MakeKomatsu
Aspirationturbocharged
