Kubota
Komatsu
PC20MR-2
Mini Excavator
30 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 3,747 lb |
|---|---|
| Operating weight Cabin | 3,967 lb |
| Fuel Capacity | 5.6 gal |
| Hydraulic Pump Flow Capacity | 3.8 gal/min |
| Hydraulic System Fluid Capacity | 7.4 gal |
Engine
| Engine Model | D902-E4-BH-3 |
|---|---|
| Displacement | 55 in³ |
| Power Measured @ | 2,050 rpm |
| Gross Power | 17.7 hp |
| Net Power | 15.2 hp |
| Number of Cylinders | 3 |
| Fuel Type | Diesel |
| Engine Type | Water cooled |
| Air filter type | Dual element |
| Injection | Indirect |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Length of Track on Ground | 146 in |
| Height | 93 in |
| Width | 40 in |
| Shoe width | 9 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Max Travel Speed | 2.5 mph |
| Drawbar Pull | 7,261 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 95 in |
|---|---|
| Max Reach Along Ground | 152 in |
| Max Vertical Wall Digging Depth | 78 in |
| Max.Dumping Height | 95 in |
| Max Digging Height | 137 in |
| Mximum dig radius | 154 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Blades
| Blade Width | 52 in |
|---|---|
| Blade Height | 9 in |
| Maximum Drop below ground | 9 in |
| Maximum Lift Above Ground | 9 in |
Electrical System
| Battery capacity | 52 Ah |
|---|---|
| Battery voltage | 12 VDC |
| Lighting | Front working |
