Kubota
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
53 data points
Operating Specifications
| Operating Weight | 9,017 lb |
|---|---|
| Fuel Capacity | 17.0 gal |
| Hydraulic Pump Flow Capacity | 6.5 gal/min |
| Hydraulic System Fluid Capacity | 17.2 gal |
| Ground Pressure | 5 psi |
Engine
| Engine Model | D1803-CR-TE4 |
|---|---|
| Displacement | 111 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 40.4 hp |
| Net Power | 38.9 hp |
| Number of Cylinders | 3 |
| Aspiration | Turbo |
| Engine Make | Kubota |
| Fuel Type | Diesel |
| Engine Type | Water cooled |
| Model Name | KX040-4HG |
| Cooling method | Liquid |
| Air filter type | Dual element cyclonic |
| Radiator Core type | Low noise F shaped blades |
| Injection | Direct |
| Oil filtration | Spin-on type |
| EPA | Tier 4 |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 98 in |
| Length of Track on Ground | 200 in |
| Tail Swing Radius | 52 in |
| Height | 98 in |
| Width | 67 in |
| Shoe width | 15 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Max Travel Speed | 3.1 mph |
Brakes & Steering
| Parking brake | Auto travel house swivel |
|---|
Boom/Stick Excavator Option 1
| Max Digging Depth | 135 in |
|---|---|
| Max Vertical Wall Digging Depth | 89 in |
| Max.Dumping Height | 154 in |
| Max Digging Height | 211 in |
| Mximum dig radius | 213 in |
| Max. breakout force Bucket | 9,535 lb |
| Max. breakoutArm | 4,112 lb |
Drive System
| Max. traction force-Low speed | 9,747 lb |
|---|
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Blades
| Blade Width | 67 in |
|---|---|
| Blade Height | 14 in |
| Maximum Drop below ground | 17 in |
| Maximum Lift Above Ground | 17 in |
| Angle blade height | 15 in |
| Angle blade swing angle | 25 ° |
| Angle blade width | 67 in |
Electrical System
| Battery capacity | 52 Ah |
|---|---|
| Battery voltage | 12 VDC |
| Engine shut-off | Key |
| Lighting | Front working |
| Instrument panel | Digital |
