Kubota
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 6,548 lb |
|---|---|
| Fuel Capacity | 11.9 gal |
| Hydraulic Pump Flow Capacity | 8.6 gal/min |
| Hydraulic System Fluid Capacity | 13.4 gal |
| Cooling System Fluid Capacity | 1.5 gal |
Engine
| Engine Model | V1505-E4 |
|---|---|
| Displacement | 91 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 26.4 hp |
| Net Power | 24.4 hp |
| Number of Cylinders | 4 |
| Engine Make | Kubota |
| Fuel Type | Diesel |
| Engine Type | Water cooled |
| Model Name | KX71-3HGLS |
| Air filter type | Dual element |
| Injection | Indirect |
| Oil filtration | Spin on type |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 96 in |
| Length of Track on Ground | 64 in |
| Tail Swing Radius | 64 in |
| Height | 12 in |
| Width | 60 in |
| Shoe width | 12 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Max Travel Speed | 2.8 mph |
| Drawbar Pull | 15,837,790 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 115 in |
|---|---|
| Max Vertical Wall Digging Depth | 83 in |
| Max.Dumping Height | 138 in |
| Max Digging Height | 186 in |
| Mximum dig radius | 189 in |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Blades
| Blade Width | 60 in |
|---|---|
| Blade Lift Height | 12 in |
| Maximum Drop below ground | 15 in |
Electrical System
| Battery capacity | 55 Ah |
|---|---|
| Battery voltage | 12VDC |
| Engine shut-off | Key |
