Kubota
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 7,518 lb |
|---|---|
| Operating weight Cabin | 7,330 lb |
| Fuel Capacity | 5.1 gal |
| Hydraulic Pump Flow Capacity | 3.5 gal/min |
| Hydraulic System Fluid Capacity | 6.1 gal |
| Travel speed, high range | 3.0 mph |
| Travel speed, low range | 2.0 mph |
| Auxiliary hydraulic flow | 16.5 gal/min |
Engine
| Engine Model | D902-E3 |
|---|---|
| Displacement | 3,344 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 29.6 hp |
| Net Power | 28.3 hp |
| Number of Cylinders | 3 |
| Engine Make | Kubota |
| Model Name | KX91-3GLS2 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Overall Length | 189 in |
| Tail Swing Radius | 52 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Shoe Size | 9 in |
| Drawbar Pull | 4,865 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 126 in |
|---|---|
| Max Vertical Wall Digging Depth | 76 in |
| Max.Dumping Height | 139 in |
| Max Digging Height | 141 in |
| Mximum dig radius | 202 in |
Boom
| Boom swing left | 65 ° |
|---|---|
| Boom swing right | 58 ° |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Blades
| Blade Width | 61 in |
|---|---|
| Blade Lift Height | 11 in |
| Maximum Drop below ground | 8 in |
| Overall Height | 97 in |
