Kubota
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 8,129 lb |
|---|---|
| Fuel Capacity | 12.4 gal |
| Hydraulic Pump Flow Capacity | 11.8 gal/min |
| Hydraulic System Fluid Capacity | 16.2 gal |
| Travel speed, high range | 2.9 mph |
| Travel speed, low range | 1.9 mph |
| Auxiliary hydraulic flow | 15.9 gal/min |
Engine
| Engine Model | D1703M-DI-E4 |
|---|---|
| Displacement | 6,133 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 24.8 hp |
| Number of Cylinders | 3 |
| Engine Make | Kubota |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Overall Length | 187 in |
| Overall Width | 67 in |
| Tail Swing Radius | 36 in |
| Crawler length | 83 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Reach Along Ground | 193 in |
|---|---|
| Max Vertical Wall Digging Depth | 80 in |
| Max.Dumping Height | 133 in |
| Max Digging Height | 191 in |
| Mximum dig radius | 208 in |
General Specifications
| Operating Weight lbs (kg) | 8,129 (3,687) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 9.10 (3) Starting 2025 Model Year |
| Engine hp (kW) | 23.9 (17.8) Starting 2025 Model Year |
| Digging Reach ft. (m) | 16.1 (5.2) Starting 2025 Model Year |
Boom
| Boom swing left | 75 ° |
|---|---|
| Boom swing right | 55 ° |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Blades
| Blade Lift Height | 14 in |
|---|---|
| Maximum Drop below ground | 13 in |
| Overall Height | 98 in |
