Leeboy
John Deere
770D
Motor Grader
66 specifications
/filters:autojpg()/filters:quality(40)/filters:extract_focal()/filters:format(webp)/mdl-leeboy-motor-grader-685b-13cea96b-2.jpg)
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Std Operation Weight - Total | 15,201 lb |
|---|---|
| Tire Size | 15/38.5-15 |
| Fuel Capacity | 39.9 gal |
| Hydraulic System Fluid Capacity | 32.0 gal |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 5.6 gal |
| Oil System Fluid Capacity | 3.0 gal |
Engine
| Engine Model | Cummins |
|---|---|
| Displacement | 238 in³ |
| Power Measured @ | 2,500 rpm |
| Max Power | 110.0 hp |
Hydraulic System
| Relief Valve Pressure | 4,500 psi |
|---|
Dimensions
| Overall Length | 260 in |
|---|---|
| Width Over Tires | 83 in |
| Height to Top of Isomount Cab | 107 in |
Transmission
| Max Speed - Forward | 20.0 mph |
|---|
Moldboard
| Moldboard Height | 18 in |
|---|---|
| Moldboard Width | 124 in |
| Side Shift Left | 36 in |
Circle
| Blade Tip Angle - Front | 30 ° |
|---|---|
| Rotation | 120 ° |
Front Axle
| Wheel Lean | 26 ° |
|---|---|
| Ground Clearance | 13 in |
