Specifications
47 data points
Operating Specifications
| Operating Weight | 61,729 lb |
|---|---|
| Fuel Capacity | 87.2 gal |
| Hydraulic Pump Flow Capacity | 61.1 gal/min |
| Hydraulic System Fluid Capacity | 113.6 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Hydraulic Pump Type | 2 Liebherr axial piston variable displacement pumps |
Engine
| Engine Model | Liebherr D934 |
|---|---|
| Displacement | 427 in³ |
| Power Measured @ | 1,700 rpm |
| Net Power | 217.0 hp |
| Number of Cylinders | 4 |
| Bore | 5 in |
| Stroke | 6 in |
| Engine Type | 4 cylinder in-line |
| Cooling system | Water-cooled |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 127 in |
| Wheelbase | 109 in |
| Overall Width | 100 in |
| Tail Swing Radius | 120 in |
Transmission
| Max Travel Speed | 12.5 mph |
|---|
Bucket
| Maximum Bucket Capacity | 2.30 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.99 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 56,054 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 248 in |
|---|---|
| Max Reach Along Ground | 389 in |
| Shipping Length of Unit | 401 in |
| Shipping Height of Unit | 125 in |
| Max Dumping Height | 306 in |
| Max breakout force | 38,128 lb |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 257 in |
|---|---|
| Max Reach Along Ground | 396 in |
| Shipping Height of Unit | 122 in |
| Shipping Length of Unit | 401 in |
| Max Dumping Height | 312 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 264 in |
|---|---|
| Max Reach Along Ground | 404 in |
| Shipping Height of Unit | 122 in |
| Shipping Length of Unit | 401 in |
Electrical System
| Batteries | 2 x 135 Ah/12 volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 278 in |
|---|---|
| Max Reach Along Ground | 418 in |
| Shipping Height of Unit | 126 in |
| Shipping Length of Unit | 401 in |
