JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 58,400 lb |
|---|---|
| Fuel Capacity | 87.0 gal |
| Hydraulic Pump Flow Capacity | 61.0 gal/min |
| Hydraulic System Fluid Capacity | 114.0 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Hydraulic Pump Type | 2 Liebherr axial piston variable displacement pumps |
Engine
| Engine Model | Liebherr D934 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 1,700 rpm |
| Net Power | 188.0 hp |
| Number of Cylinders | 4 |
| Bore | 5 in |
| Stroke | 6 in |
| Engine Type | 4 cylinder in-line |
| Cooling system | Water-cooled |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 108 in |
| Overall Width | 99 in |
| Tail Swing Radius | 128 in |
Transmission
| Max Travel Speed | 15.5 mph |
|---|
Bucket
| Maximum Bucket Capacity | 2.20 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.80 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 56,054 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 250 in |
|---|---|
| Max Reach Along Ground | 389 in |
| Shipping Length of Unit | 396 in |
| Shipping Height of Unit | 125 in |
| Max Dumping Height | 306 in |
| Max breakout force | 32,400 lb |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 257 in |
|---|---|
| Max Reach Along Ground | 396 in |
| Shipping Height of Unit | 122 in |
| Shipping Length of Unit | 396 in |
| Max Dumping Height | 396 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 226 in |
|---|---|
| Max Reach Along Ground | 361 in |
| Shipping Height of Unit | 130 in |
| Shipping Length of Unit | 373 in |
Electrical System
| Batteries | 2 x 135 Ah/12 volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 233 in |
|---|---|
| Max Reach Along Ground | 379 in |
| Shipping Height of Unit | 130 in |
| Shipping Length of Unit | 384 in |
