Liebherr
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Operating Weight | 17,020 lb |
|---|---|
| Fuel Capacity | 37.0 gal |
| Tire Size | 15.5R25 or 17.5R25 |
| Hydraulic System Fluid Capacity | 27.8 gal |
| Static Tipping Weight | 12,511 lb |
| Operating Voltage | 12 V |
| Turning Radius | 175 in |
| Engine Oil Fluid Capacity | 3.6 gal |
| Rear Axle Oscillation | 12 ° |
| Alternator Supplied Amperage | 65 A |
| Front Axle/Diff Fluid Capacity | 3.4 gal |
| Rear Axle/Diff Fluid Capacity | 0.2 gal |
Engine
| Engine Model | D 504 T |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 98.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Inline engine water-cooled exhaust-turbo charged |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 30.4 gal/min |
|---|---|
| Raise Time | 4.5 s |
| Lower Time | 3.0 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 3,336 psi |
| Pump Type | Gear pump |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 120 in |
| Wheelbase | 103 in |
| Reach at Max Lift and Dump | 33 in |
| Length with Bucket on Ground | 244 in |
| Hinge Pin - Max Height | 145 in |
Transmission
| Max Speed - Forward | 18.7 mph |
|---|---|
| Max Speed - Reverse | 18.7 mph |
| Transmission Type | Stepless hydrostatic travel drive |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Bucket Capacity - heaped | 2.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 111 in |
| Breakout Force | 17,310 lb |
| Bucket Width | 95 in |
