Liebherr
JCB
436HT Super High Lift
Wheel Loader
45 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 23,775 lb |
|---|---|
| Fuel Capacity | 45.0 gal |
| Tire Size | 17.5R25 |
| Hydraulic System Fluid Capacity | 45.0 gal |
| Static Tipping Weight | 17,875 lb |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 3.2 gal |
| Rear Axle Oscillation | 12 ° |
| Alternator Supplied Amperage | 55 A |
| Front Axle/Diff Fluid Capacity | 4.4 gal |
| Rear Axle/Diff Fluid Capacity | 4.0 gal |
Engine
| Engine Model | D 504 Tl |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 115.4 hp |
| Number of Cylinders | 4 |
| Aspiration | turbo-charged |
| Torque Measured @ | 1,500 rpm |
Hydraulic System
| Pump Flow Capacity | 27.8 gal/min |
|---|---|
| Raise Time | 6.6 s |
| Lower Time | 4.0 s |
| Dump Time | 1.8 s |
| Relief Valve Setting | 4,569 psi |
| Pump Type | Load-sensing variable axial piston pump with output and flow control and pressure cut-off in the control block |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 113 in |
| Length with Bucket on Ground | 274 in |
| Hinge Pin - Max Height | 149 in |
Transmission
| Max Speed - Forward | 24.9 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Transmission Type | hydrostatic |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 2.90 yd³ |
|---|---|
| Dump Clearance at Max Raise | 139 in |
| Bucket Width | 100 in |
