Liebherr
Hitachi
EX5500-5
Mini Excavator
46 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 1,764,000 lb |
|---|---|
| Standard bucket capacity- SAE | 68.09 yd³ |
Engine
| Engine Model | Cummins QSK60 |
|---|---|
| Displacement | 3,662 in³ |
| Bore | 6 in |
| Stroke | 8 in |
| Engine Type | 16 cylinder V-engine |
| Alternator | 260 A |
| Air cleaner | Dry-type air cleaner with pre-cleaner with automatic dust ejector primary and safety elements |
| Rated Engine Speed | 1,800 rpm |
| Rated Power | 4,001.8 hp |
Hydraulic System
| Maximum system pressure | 4,640 psi |
|---|---|
| Pump Flow | 1,981.1 gal/min |
Dimensions
| Wheelbase | 319 in |
|---|---|
| Overall Width | 346 in |
| Track Width | 264 in |
| Overall height with ROPS | 407 in |
| Overall length - bucket level on ground | 941 in |
Fluid Capacities
| Fuel Tank | 4,648.2 gal |
|---|---|
| Hydraulic system | 2,641.5 gal |
| Hydraulic Tank | 1,532.0 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 355 in |
|---|---|
| Max.Dumping Height | 430 in |
| Boom/Stick Option (HEX) 1 | 11.75 m (38.55 ft) |
| Bucket Digging Force - ISO | 395,664 lb |
| Maximum Reach at Ground Level | 792 in |
| Breakout force - ISO | 445,122 lb |
| Ground Pressure | 39 psi |
| Max. teeth height | 7,654 in |
| Stick length | 198 in |
Boom/Stick Excavator Option 3
| Boom/Stick Option (HEX) 3 | 8.55 m (28.05 ft) |
|---|---|
| Max bucket opening width | 119 in |
| Max.Dumping Height | 489 in |
| Breakout force-ISO | 538,417 lb |
| Ground pressure | 39 psi |
| Max. crowd force | 674,427 lb |
| Max. crowd force at ground level (ISO 6015) | 651,946 lb |
| Max. crowd length | 214 in |
| Maximum Reach at Ground Level | 630 in |
| Stick length | 215 in |
Electrical System
| Voltage | 24 V |
|---|---|
| Batteries | 8 x 170 Ah / 12 V (Cummins)/ 12 x 170 Ah / 12 V (MTU) starting battery 4 x 170 Ah / 12 V service systems |
Swing System
| Hydraulic motors and drives | 4 Liebherr axial piston motors |
|---|---|
| Swing gear | 4 Liebherr planetary reduction gears |
| Swing ring teeth | Liebherr sealed triple roller swing ring internal teeth |
| Swing speed | 4 rpm |
