LiebherrLiebherr
R995
Mini Excavator
85 specifications
1 / 5
Image 1 of 5
Specifications
56 data points
Operating Specifications
| Fuel Capacity | 3,433.9 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 222.0 gal/min |
| Hydraulic System Fluid Capacity | 2,166.1 gal |
| Hydraulic System Relief Valve Pressure | 4,640 psi |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 150 A |
| Swing Speed | 4 rpm |
Engine
| Engine Model | 2 x K 1800 E |
|---|---|
| Displacement | 3,070 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 3,000.0 hp |
| Net Power | 3,000.0 hp |
| Number of Cylinders | 16 |
Dimensions
| Ground Clearance | 57 in |
|---|---|
| Height - Top of Cab | 357 in |
| Length of Track on Ground | 296 in |
| Width to Outside of Tracks | 301 in |
| Removal Counterweight Clearance | 113 in |
| Digging Depth | 336 in |
| Digging Reach | 336 in |
| Upper Structure Ground Clearance | 113 in |
| Length of Tracks | 395 in |
| Height of Tracks | 118 in |
Undercarriage
| Ground Pressure | 40 psi |
|---|---|
| Track Gauge | 236 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 1.4 mph |
| Shoe Size | 55 in |
| Number of Carrier Rollers per Side | 3 |
| Number of Upper Rollers | 3 |
| Loading Shovel Operating Weight | 1,472,688 lb |
| Loading Shovel Shoe Width | 55 in |
| Loading Shovel Ground Pressure | 41 psi |
| Number of Lower Rollers | 7 |
| Backhoe Shoe Width 1 | 55 in |
| Backhoe Operating Weight - Shoe 1 | 1,452,846 lb |
| Backhoe Ground Pressure - Shoe 1 | 40 psi |
Boom/Stick Excavator Option 1
| Max Digging Depth | 347 in |
|---|---|
| Max Reach Along Ground | 789 in |
| Max Loading Height | 414 in |
| Shipping Length of Unit | 891 in |
| Max Cutting Height | 654 in |
| Shipping Height of Unit | 384 in |
Swing Mechanism
| Swing Speed | 4 rpm |
|---|
Loading Shovel
| Max Dig Reach | 615 in |
|---|---|
| Max Dump Height | 564 in |
| Arm Crowd Force | 516,973 lb-ft |
| Loading Shovel | 8m boom / 5m stick |
| Height to Top of Boom - shovel | 335 in |
| Overall Length - shovel | 924 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 347 in |
|---|---|
| Max Cutting Height | 654 in |
| Max Dump Height | 414 in |
| Max Reach on Ground | 789 in |
| Height to Top of Boom | 384 in |
| Overall Length | 891 in |
