Liebherr
Caterpillar
773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Fuel Capacity | 929.8 gal |
|---|---|
| Tire Size | 40R57 |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 75 A |
| Steering System Fluid Capacity | 125.0 gal |
| Brake/Hoist System Fluid Capacity | 350.1 gal |
Engine
| Engine Model | DDC/MTU 12V4000 |
|---|---|
| Gross Power | 2,500.0 hp |
| Aspiration | 75 amps |
Weights
| Empty Weight | 345,994 lb |
|---|---|
| Loaded Weight | 860,001 lb |
Dimensions
| Wheelbase | 241 in |
|---|---|
| Overall Length | 524 in |
| Overall Width | 292 in |
| Overall Height | 264 in |
| Dump Height | 233 in |
Transmission
| Max Speed | 32.0 mph |
|---|
Dump
| Rated Payload | — |
|---|---|
| Dump Angle | 50 ° |
| Raise Time | 21.0 s |
| Lower Time | 14.0 s |
| Load Capacity - heaped | 155.70 yd³ |
| Load Capacity - Struck | 109.89 yd³ |
