Link Belt
Terex
A600
Rough Terrain Crane
31 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 92,995 lb |
|---|---|
| Fuel Capacity | 75.0 gal |
| Tire Size | 26.5 x 25 |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 173.0 gal |
| Alternator Supplied Amperage | 140 A |
| DEF tank capacity | 5.0 gal |
Engine
| Engine Model | C6.6 |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 270.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 730 lb-ft |
| Engine Make | Cummins QSB |
| Stroke | 5 in |
| Bore | 4 in |
| Emissions compliance | Tier 4F / Stage IV |
| Crankcase capacity | 3.8 gal |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 175 in |
| Transport Width | 126 in |
| Transport Height | 154 in |
| Transport Length | 568 in |
| Width w/ Outriggers Extended | 312 in |
| Upper Structure Tail Swing Radius | 162 in |
| Carrier/Base Length | 322,835 in |
Transmission
| Max Speed - Forward | 20.8 mph |
|---|---|
| Max Speed - Reverse | 20.8 mph |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | Powershift |
Boom
| Max Elevating Angle | 80 ° |
|---|---|
| Min Operating Radius | 91 in |
