Grove
RT625
Rough Terrain Crane
38 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 42,484 lb |
|---|---|
| Fuel Capacity | 62.0 gal |
| Tire Size | 17.5 x 25 |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 95.0 gal |
| Alternator Supplied Amperage | 42 A |
Engine
| Engine Model | 19450 |
|---|---|
| Displacement | 212 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 136.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 282 lb-ft |
| Engine Make | General Motors |
| Bore | 4 in |
| Stroke | 5 in |
| Crankcase capacity | 3.5 gal |
Hydraulic System
| Maximum operating pressure | 2,800 psi |
|---|
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 114 in |
| Transport Width | 97 in |
| Transport Height | 124 in |
| Transport Length | 410 in |
| Width w/ Outriggers Extended | 196 in |
| Upper Structure Tail Swing Radius | 108 in |
| Carrier/Base Length | 229 in |
Transmission
| Max Speed - Forward | 24.0 mph |
|---|---|
| Max Speed - Reverse | 9.1 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
| Transmission Type | Allison TT-2221-1 Powershift |
Boom
| Max Height @ Max Raise Angle - no jib | 721 in |
|---|---|
| Min Height @ Max Raise Angle | 300 in |
| Number of Sections | 3 |
| Swing Speed | 3 rpm |
