Link Belt

HTC-25

Truck Crane

Operating Weight
45,625 lb
Max Speed - Forward
53.8 mph
Displacement
318 in³
All truck cranes
Link Belt HTC-25 Truck Crane
1 / 5
Image 1 of 5
Image: cranenetwork.com

Specifications

27 data points

Operating Specifications

Operating Specifications specifications
Operating Weight45,625 lb
Operating Voltage12 V
Carrier Fuel Capacity60.0 gal
Upper Structure Hydraulic System Fluid Capacity160.0 gal
Carrier Hydraulic System Fluid Capacity91.0 gal

Dimensions

Dimensions specifications
Ground Clearance11 in
Transport Width96 in
Transport Height118 in
Transport Length408 in
Width w/ Outriggers Extended204 in
Upper Structure Tail Swing Radius128 in
Carrier Length355 in

Transmission

Transmission specifications
Max Speed - Forward53.8 mph
Max Speed - Reverse19.5 mph
Number of Forward Gears13
Number of Reverse Gears3
Transmission TypeEaton Roadranger RT613

Boom

Boom specifications
Swing Speed4 rpm

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power216.0 hp
Displacement318 in³
Power Measured @2,800 rpm
MakeLink-Belt
Max Torque440 lb-ft
Torque Measured @1,800 rpm
Number of cylinders6
bore4 in
Stroke5 in
