Link Belt

HTC-35

Truck Crane

Operating Weight
60,883 lb
Max Speed - Forward
49.0 mph
Displacement
318 in³
All truck cranes
Link Belt HTC-35 Truck Crane
1 / 5
Image 1 of 5
Image: veritread.com

Specifications

29 data points

Operating Specifications

Operating Specifications specifications
Operating Weight60,883 lb
Operating Voltage12 V
Tire Size11.00 x 20
Carrier Fuel Capacity60.0 gal
Upper Structure Hydraulic System Fluid Capacity236.0 gal

Dimensions

Dimensions specifications
Ground Clearance11 in
Transport Width96 in
Transport Height120 in
Transport Length479 in
Width w/ Outriggers Extended217 in
Upper Structure Tail Swing Radius142 in
Carrier Length419 in

Transmission

Transmission specifications
Max Speed - Forward49.0 mph
Max Speed - Reverse17.7 mph
Number of Forward Gears13
Number of Reverse Gears3
Transmission TypeEaton Roadranger RT613

Boom

Boom specifications
Max Height @ Max Raise Angle - no jib960 in
Min Height @ Max Raise Angle384 in
Swing Speed3 rpm

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power216.0 hp
Displacement318 in³
Power Measured @2,800 rpm
MakeLink-Belt
Max Torque446 lb-ft
Torque Measured @1,800 rpm
Number of cylinders6
bore4 in
Stroke5 in
