Link Belt
RTC-8060
- Operating Weight
- 83,482 lb
- Max Lift Capacity
- 132,277 lb
- Max Speed - Forward
- 19.9 mph
- Gross Power
- 225.0 hp
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 83,482 lb |
|---|---|
| Fuel Capacity | 95.0 gal |
| Tire Size | 29.5 x 25 |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 170.0 gal |
| Alternator Supplied Amperage | 130 A |
Engine
| Engine Model | 3126B |
|---|---|
| Displacement | 439 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 225.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 646 lb-ft |
| Engine Make | Caterpillar |
| Stroke | 5 in |
| Bore | 4 in |
| Emissions compliance | Tier 4F / Stage IV |
| Crankcase capacity | 7.4 gal |
Dimensions
| Wheelbase | 151 in |
|---|---|
| Transport Width | 131 in |
| Transport Height | 155 in |
| Transport Length | 559 in |
| Width w/ Outriggers Extended | 265 in |
| Upper Structure Tail Swing Radius | 139 in |
| Carrier/Base Length | 327,559 in |
Transmission
| Max Speed - Forward | 19.9 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 2 |
| Transmission Type | Power shift |
Boom
| Max Lift Capacity | 132,277 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,321 in |
| Min Height @ Max Raise Angle | 426 in |
| Max Elevating Angle | 78 ° |
| Number of Sections | 4 |
| Swing Speed | 2 rpm |
| Height | 1,380 in |
