JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 48,281 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 111.0 gal/min |
| Hydraulic System Relief Valve Pressure | 4,641 psi |
Engine
| Engine Model | 6BT5.9 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 144.9 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 109 in |
| Width to Outside of Tracks | 119 in |
Undercarriage
| Max Travel Speed | 3.1 mph |
|---|---|
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 261 in |
|---|---|
| Max Reach Along Ground | 389 in |
| Max Loading Height | 268 in |
| Max Vertical Wall Digging Depth | 223 in |
| Shipping Length of Unit | 376 in |
| Shipping Height of Unit | 118 in |
Bucket
| Reference Bucket Capacity | 1.20 yd³ |
|---|
