Massey Ferguson
Branson
4720h
Tractor
20 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 27.0 gal |
|---|
Engine
| Engine Model | 33 AWIC |
|---|---|
| Displacement | 201 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 90.0 hp |
| Number of Cylinders | 3 |
| Aspiration | Turbocharged |
| Engine Make | AGCO Power |
| PTO Power | 72.0 hp |
Weights
| Weight 4WD With ROPS | 6,394 lb |
|---|---|
| Weight (shipping, 4WD, cab, flange axle) | 6,834 lb |
Hydraulic System
| Pump Flow Capacity | 23.7 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Hydraulic System Type | Open Center system |
| Pump Type | Gear type single pump |
Dimensions
| Height - Top of Cab | 103 in |
|---|---|
| Wheelbase | 89 in |
| Overall Length | 153 in |
| Overall Width | 79 in |
Transmission
| Transmission Type | 12F x 12R Power shuttle |
|---|
Production
| Series | 4600 Series |
|---|---|
| Years Manufactured | 2,013 – 2,015 |
Electrical System
| Alternator | 95 |
|---|---|
| Battery | 12 V |
3-Point Hitch
| Lift capacity @ 24in. (ASAE) | 3,417 lb |
|---|---|
| Extendable lower links | Extendable ball ends |
Power Take-Off (PTO)
| Power Take-Off(PTO) Type | Electronically engaged |
|---|---|
| PTO speed | 540 rpm |
| Optional | Independent |
| PTO Speeds @ Engine rpm | 1,000 |
