Mec

2633ES

Aerial Lift

Max Platform Height
312 in
Overall Length
8 in
Overall Width
33 in
All aerial lifts
Mec 2633ES Aerial Lift
1 / 5
Image 1 of 5
Image: aerialequipmentparts.com

Specifications

21 data points

Engine

Engine specifications
System Voltage24 V
Battery Amp Hours220
Number of Batteries4
Charger Amps25

Dimensions

Dimensions specifications
Ground Clearance4 in
Wheelbase72 in
Overall Length8 in
Overall Width33 in
Turning Radius89 in
Height w/ Rails86 in

Performance

Performance specifications
Operating Weight3,829 lb
Max Speed3.0 mph
Tire Size16x5
Hydraulic System Fluid Capacity3.0 gal
Tire Fill/TypeSolid non-marking

Platform

Platform specifications
Max Platform Height312 in
Max Platform Weight Capacity500 lb
Platform Inner Length91 in
Max Working Height391 in
Deck Extension42 in
Height of Rails44 in
