Mitsubishi
Caterpillar
120G
Motor Grader
17 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Std Operation Weight - Total | 39,430 lb |
|---|---|
| Tire Size | 16.00-24-12PR |
| Operating Voltage | 24 V |
Engine
| Engine Model | C 6D22-T |
|---|---|
| Displacement | 680 in³ |
| Power Measured @ | 2,200 rpm |
| Max Power | 210.0 hp |
| Net Power Gears 7-8 | 210.0 hp |
Dimensions
| Wheelbase | 254 in |
|---|---|
| Overall Length | 379 in |
| Width Over Tires | 111 in |
| Height to Top of Isomount Cab | 114 in |
Transmission
| Max Speed - Forward | 27.1 mph |
|---|---|
| Max Speed - Reverse | 27.7 mph |
| Number of Gears - Forward | 8 |
| Number of Gears - Reverse | 8 |
| Transmission Type | power shift planetary gear hydraulically actuated |
Moldboard
| Moldboard Height | 28 in |
|---|---|
| Moldboard Width | 170 in |
| Moldboard Thickness | 1 in |
Steering System
| Turning Radius | 296 in |
|---|
