Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Fuel Capacity | 129.5 gal |
|---|---|
| Tire Size | 29.5R25 |
| Engine Oil Capacity | 3.5 gal |
| Cooling System Fluid Capacity | 13.3 gal |
| Hydraulic System Fluid Capacity | 72.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
| Transmission Fluid Capacity | 14.6 gal |
Engine
| Engine Model | DC 12 |
|---|---|
| Displacement | 714 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 443.9 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 1,367 lb-ft |
| Make | Scania |
Weights
| Operating Weight | 143,631 lb |
|---|---|
| Total Empty | 59,856 lb |
| Front Axle - empty | 30,754 lb |
| Total Loaded | 141,868 lb |
| Rear Axle - empty | 29,101 lb |
| Front Axle - loaded | 44,093 lb |
| Rear Axle - loaded | 97,775 lb |
Dimensions
| Ground Clearance | 26 in |
|---|---|
| Wheelbase | 211 in |
| Overall Length | 411 in |
| Overall Width | 138 in |
| Overall Height | 150 in |
| Dump Height | 258 in |
| Dump Ground Clearance | 32 in |
Transmission
| Max Speed | 33.0 mph |
|---|---|
| Transmission Type | ZF 6 WG 310 Dash 4 electronically-controlled automatic |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Drive System
| Drive Config | 6X6 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 82,012 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 12.0 s |
| Lower Time | 11.0 s |
| Capacity - Heaped | 31.40 yd³ |
| Capacity - Struck | 24.20 yd³ |
