Mustang
Bobcat
773
Skid Steer Loader
17 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 4,600 lb |
|---|---|
| Max Speed | 6.4 mph |
| Fuel Capacity | 12.4 gal |
| Hydraulic System Fluid Capacity | 10.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 650 A |
Engine
| Engine Model | 4TNV88 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 46.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 16.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,750 psi |
Dimensions
| Height - Top of Cab | 110 in |
|---|---|
| Wheelbase | 37 in |
| Width Over Tires | 59 in |
| Reach at Max Lift and Dump | 8 in |
| Length with Bucket | 117 in |
| Clearance at Max Lift and Dump | 88 in |
| Turning Radius from Center - inc bucket | 69 in |
| Turning Radius from Center - machine rear | 58 in |
| Length w/o Bucket | 91 in |
Loader
| Bucket Capacity | 0.41 yd³ |
|---|---|
| Operating Load Rating | 1,475 lb |
| Tipping Angle | 2,700 ° |
| Operating Width | 55 in |
| Breakout Force | 2,800 psi |
