Mustang
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 8,002 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 31.2 gal/min |
| Hydraulic System Relief Valve Pressure | 3,046 psi |
Engine
| Engine Model | 3TNV88-NNS |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 36.4 hp |
| Net Power | 28.8 hp |
| Number of Cylinders | 3 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 98 in |
| Length of Track on Ground | 64 in |
| Tail Swing Radius | 35 in |
| Width to Outside of Tracks | 69 in |
| Removal Counterweight Clearance | 16 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 67 in |
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.9 mph |
| Shoe Size | 23 in |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 10,053 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 132 in |
|---|---|
| Max Reach Along Ground | 215 in |
| Max Vertical Wall Digging Depth | 106 in |
| Max Loading Height | 132 in |
| Shipping Length of Unit | 190 in |
| Max Cutting Height | 219 in |
| Shipping Height of Unit | 98 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.30 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 57,777 lb-ft |
