Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 7,430 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 17.8 gal/min |
Engine
| Displacement | 81 in³ |
|---|---|
| Power Measured @ | 2,400 rpm |
| Net Power | 26.7 hp |
| Number of Cylinders | 4 |
Dimensions
| Length of Track on Ground | 65 in |
|---|---|
| Tail Swing Radius | 56 in |
| Width to Outside of Tracks | 62 in |
Undercarriage
| Max Travel Speed | 2.8 mph |
|---|---|
| Shoe Size | 12 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 124 in |
|---|---|
| Max Reach Along Ground | 204 in |
| Max Vertical Wall Digging Depth | 91 in |
| Max Loading Height | 141 in |
| Shipping Length of Unit | 198 in |
| Shipping Height of Unit | 96 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|
